Auto Pipe Welding Positioners Self Aligned , Welding Manipulators
Auto tank welding widely used self aligned polyurethane roll welding rotator Names
Self-aligning welding turn roll , self-aligning rotator , Self-aligning roll bed , welding turning roll , welding rotator , roll bed , self adjustable turning roll , self adjustable rotator , self adjustable roll bed , pipe welding turning roll , pipe welding rotator , pipe welding roll bed ,pipe welding roller ,conventional welding turning roll , conventional welding rotator , conventional welding roll bed , blasting turning roll , blasting rotator , blasting roll bed , painting turning roll , painting rotator , painting roll bed etc.
Auto tank welding widely used self aligned polyurethane roll welding rotator Description
1. Auto tank welding widely used self aligned polyurethane roll welding rotator absorbing domestic and international advanced equipment.
2. Auto tank welding widely used self aligned polyurethane roll welding rotator mainly used for big pipe, containers, boilers, pressure vessels, oil tank, wind tower and other cylinders assembly welding, blasting and painting.
3. Auto tank welding widely used self aligned polyurethane roll welding rotator can assort all kinds of auto welding or manual welding, improving welding quality, reducing the labor and improving productivity.
4. Auto tank welding widely used self aligned polyurethane roll welding rotator series includes the self-alignment, the adjustable, the vehicle, the tilting and the anti-drift types.
Auto tank welding widely used self aligned polyurethane roll welding rotator Application
1. Pressure vessels
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
5. Any heavy cylindrical job
Auto tank welding widely used self aligned polyurethane roll welding rotator Feature:
Auto tank welding widely used self aligned polyurethane roll welding rotator is used to weld, polish and assemble the cylinder-vessel . When put on the vesse , it can be aligned by itself according to the size of the vessel , it adopts AC variable frequency drive, so the linear speed can be adjust according to customer's requirements . Also the linear speed can be displayed by the digital uint . It has advantages of stepless speed adjust, low noise transmission and stable turning under the welding parameter in the range. We also can design and customize various types of the welding rollbed in accordance with the customers requirement.
Auto tank welding widely used self aligned polyurethane roll welding rotator Main Technical Parameter
| Main technical parameter |
| Model | HGZ-5 | HGZ-10 | HGZ-20 | HGZ-40 | HGZ-60 | HGZ-80 | HGZ-100 | HGZ-200 | HGZ-300 |
| Rated loading (T) | 5 | 10 | 20 | 40 | 60 | 80 | 100 | 200 | 300 |
| Vessel diameter range (mm) | 250-2300 | 320-2800 | 500-3500 | 600-4200 | 750-4800 | 850-5000 | 1000-500 | 1000 -6500 | 1000 -7000 |
| PU roller dia. and width (mm) | 250*100 | 300*120 | 350*140 | 400*180 | 400*180*2 | 450*200*2 | 500*240*2 | 600*3250*2 | / |
| Metal roller dia. and width (mm) | / | / | / | / | / | / | / | / | 750*280 |
| Linear speed (mm/min) | 100-1000 |
| Speed control | Variable Frenquency Drive speed control |
| Motor power (kW) | 0.75 | 1.1 | 1.5 | 3 | 4 | 4 | 5.5 | 2*5.5 | 2*5.5 |
| Traveling speed - Optional (mm/min) | 3000mm/min |
| Traveling motor - Optional (kW) | 2*0.37 | 2*0.55 | 2*0.75 | 2*1.1 | 2*1.5 | 2*2.2 | 2*3 | 2*4 | 2*5.5 |
Production
What Ronniewell can do for Ronniewell customers:
1. Give you high quality products.
2. Give you five-star price.
3. Give you suitable recommendation.
4. Give you good after-service.
5. Give you professional technical guide.
6. Warmly welcome you visit our factory.
